Hörku Kerrur
4536 kg dráttarspspils 12v
4536 kg dráttarspspils 12v
Regular price
149.000 ISK
Regular price
Sale price
149.000 ISK
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Product attributes
| Dedicated : |

|
| Voltage: | 12V |
| Motor: | 6,8 HP |
| Pulling rate: | 10000 lb/ 4536 kg |
| Gear train: | 3 stage planetary |
| Reduction rotio: | 265:1 |
| Brake: | dynamic |
| Length of the steel cable: | 24 m |
| Weight: | 35 kg |
| Mounting bolt patern: | 164 mm x 114 mm |
| Overall product dimensions (LxWxH): | 450mm x 153mm x 228 mm |
CABLE WINDING SPEED AND POWER CONSUMPTION (THE FIRST CABLE LAYER ON THE DRUM)
| CABLE LOAD | kg | - | 1814 | 4536 |
| CABLE SPEED | m/min | 5,9 | 3,6 | 1,3 |
| POWER CONSUMPTION | amp | 50 | 180 | 390 |
PULLING FORCE DEPENDING ON CABLE LAYER
| CABLE LAYER | 1 | 2 | 3 | 4 | 5 | |
| CABLE PULL | kg | 4536 | 3583 | 3084 | 2676 | 2270 |
| CABLE LENGTH ON THE DRUM | m | 3,6 | 7,8 | 12,4 | 17,8 | 24,0 |
